Fabtech 2026 – HMT Show Specials

FABTECH 2026 – HMT Show Specials

HMT will be demonstrating three all-electric benders at the FABTECH 2026 show in Las Vegas. All benders are available for purchase and delivery after the conclusion of the show.

Horn 3.0ECNC-MS All-Electric CNC

  • Fastest production bender in the world, more parts per shift for meeting deadlines
  • Designed for 24/7 operation, heavy duty design and all axes are direct drive (no belts)
  • Fast setup & change over times, no manual adjustments are required
  • Mount up to 7 stacks of tools, reduced setup times for complex part bending
  • Bender utilizes linear rails & bearings, no pins, bushings, toggles, or wear plates
  • Absolute encoder technology, homing of axes is never required



  • Reduced power consumption, bender only uses power as required
  • Lower maintenance cost due to automatic lubrication system and superior design
  • Electric servos operate with minimal noise as compared to hydraulic machines
  • Servos, drives, and bearings, are readily available if a replacement is required
  • Remote troubleshooting availability with a quick diagnosis free of charge



  • Number one tube bender control in North America with support nationwide
  • Easy & intuitive software; preferred by operators & engineers
  • Import CAD files directly into BendPro for automatic part program creation
  • Offline part development software with simulation is available as an option
  • Capable of interfacing with measuring machines for fast part corrections
  • IoT / Industry 4.0 capability for sharing information captured by the bender control



Horn Metric CNC50TSRE2 All-Electric CNC



  • All axes are electric servo driven, which allows for setup times in about five minutes
  • High speed all-electric servos result in faster cycle times & increased productivity
  • Each axis can be precisely controlled for greater part optimization & efficiency
  • Manufactured with durable linear bearings & rails, which eliminates wearing parts
  • Absolute encoder technology never requires homing of the machine



  • 2.00″ All-electric, 8-Axis, Single-Stack CNC
  • RH (CW) rotation
  • Overhead tie bars for PD & Swing Arm
  • Fabtech tool set is available (1.50″OD x 3.00″CLR)
  • 126.0″ Bed Length (stopped collet)
  • Safety laser floor scanner
  • Freight prepaid to destination
  • Onsite start-up & training



  • Number one tube bender control in North America with support worldwide
  • Easy & intuitive software; preferred by operators & engineers
  • Import CAD files directly into BendPro for automatic part program creation
  • Offline part development software with simulation is available as an option
  • CMM interface for automatic part corrections are available as an option
  • IoT / Industry 4.0 capability for sharing information captured by the bender control



Horn Metric CNC80TSRE2-RBE All-Electric CNC





  • All axes are electric servo driven, which allows for setup times in about five minutes
  • High speed all-electric servos result in faster cycle times & increased productivity
  • Each axis can be precisely controlled for greater part optimization & efficiency
  • Manufactured with durable linear bearings & rails, which eliminates wearing parts
  • Absolute encoder technology never requires homing of the machine



  • 3.00″ All-electric, 8-Axis, Single-Stack CNC
  • RH (CW) rotation
  • Overhead tie bars for PD & Swing Arm
  • electric carriage boost
  • 157.5″ Bed Length (stopped collet)
  • Safety laser floor scanner
  • Freight prepaid to destination
  • Onsite start-up & training



  • Number one tube bender control in North America with support worldwide
  • Easy & intuitive software; preferred by operators & engineers
  • Import CAD files directly into BendPro for automatic part program creation
  • Offline part development software with simulation is available as an option
  • CMM interface for automatic part corrections are available as an option
  • IoT / Industry 4.0 capability for sharing information captured by the bender control



Horn Metric CNC80TBRE Handrail Bender

All-Electric Design Features

  • Dual-Stack, 5-Axis hybrid CNC handrail bender
  • Electric servo driven swing arm
  • Roll forming (large radius generation) capability
  • BendPro G2v3 Control with ability to import STEP, IGES, & Tekla, files
  • Extended bend length (240″ stopped collet) to minimize welds
  • Heavy duty B-Axis plus brake motor to rotate long heavy handrail parts
  • Mandrel extractor, plus three mandrel rods for tight radius bending (typically 3.00″CLR)
  • Automatic mandrel lubrication system for gels or pastes
  • Removable wiper system for applications that require wiper dies
  • Servo X-Axis for shifting between stacks or minimizing witness marks
  • Optional cope and feature detection system for orientating notched pipes automatically
  • Safety laser floor scanner to protect operators and plant personnel
  • Onsite start-up and training



Horn Metric CNC80TSR Longbed Handrail Bender

Hydraulic Design Features

  • Single-stack, 3-Axis hydraulic CNC handrail bender
  • BendPro G2v3 Control with ability to import STEP, IGES, and Tekla files
  • Parker proportional valve on C-Axis for increased speeds and accuracy
  • Extended bed length (240″ stopped collet) to minimize welds
  • Heavy duty B-Axis plus brake motor to rotate long heavy handrail parts
  • Mandrel extractor plus three mandrel rods for tight radius bending (typically 3.00″CLR)
  • Automatic mandrel lubrication system for gels or pastes
  • Removable wiper system for applications that require wiper dies
  • Hydraulic carriage and mandrel shift for square and rectangular tube applications
  • Optional cope and feature detection system for orientating notched pipes automatically
  • Safety laser floor scanner to protect operators and plant personnel
  • Onsite start-up and training
  • 1-1/4 IPS and 1-1/2 IPS handrail tooling available for purchase



Horn Metric LS150-4C Automatic Tube Laser





  • Precitec 4-axis laser hear
  • Rear chuck design capable of 4.00″ waste
  • 3kw Raycus fiber laser source
  • 24′ automatic bundle loader
  • 10′ max unloading length
  • Weld seam detection
  • High pressure air compressor
  • Powered fume extractor



  • Tube capacity 6.00″OD / 4.00″SQ
  • Loading length 24′
  • Max unloading length 10′
  • Max mild steel butting thickness 0.472″
  • Max stainless steel cutting thickness 0.315″



This LS150-4C is equipped with a fully automatic heavy duty bundle loader capable of singulating a tube from the bundle, measuring the length of the tube, and loading it into the machine without operator assistance. While the machine is processing the first tube, the next tube is being singulated and measured, to reduce loading times. The max bundle weight is 2.50 tons and the max single tube weight is 220 lbs.

2026 Fabtech Sales Promotion

  • Price valid for HMT quotations dated from 8/1/26 through 12/15/26
  • Deposits must be received by 12/19/26
  • Customer does not need to attend 2026 Fabtech show in Las Vegas
  • HMT will pay frieght and insurance to destination (continental US states only)
